4 layer roller veneer drying machine capacity 4 cbm one hour
big roller , high capacity
1. The Surpreme heat exchange system improves the energy utilization rate and saves unnecessary energy waste.
2. Automatic temperature control and speed regulation system, which can accurately control the final moisture content.
3. The temperature in the burner is 40-60 ℃ higher than that of the traditional dryer (steam, thermal oil),
and the temperature is controlled at 140-180 ℃, which shortens the drying time and increases the output.
4. After drying, the veneer is smooth, with no cracks, wrinkles, or end ripples.
5. Shrinkage and hardening are kept to a minimum and veneer collapse and honeycomb structure are avoided.
6. We have a professional R&D team which can design different models according to customer’s special requirement.
7. The perfect after-sale service team can supply 24 hours online service.
Model Technical parameters | PRSVD4GT | |||
Working width mm | 2800mm | |||
Working layers | 4 | |||
Length of heating section mm | 12×2000mm=24000mm | |||
Length of cooling section mm | 2×2000=4000mm | |||
Total power kw | 228.5kw | |||
Transport motor kw | 7.5×4= 30kw | |||
Heating motor kw | 15KW×12=180kw | |||
Cooling motor kw | 4KWX 4=16kw | |||
Front and back conveyor kw | 1.5×2=3kw | |||
Veneer transportation speed m/min | 2-15 | |||
Heating medium | Heat conduction oil | |||
Drying temperature ℃ | 150~170 | |||
Heat Oli consumption kcal/h | 2,500,000 | |||
Veneer density kg/m³ | ~600 | |||
Available veneer thickness mm | 1.5~4.0 | |||
Veneer initial moisture content % | ~ 65 | |||
Veneer final moisture content % | 8~ 10 | |||
Drying capacity m³/h | ~4 | |||
Load ratio % | 85 | |||
Center distance of roller mm | 333 | |||
Temperature controller mm | 2P pcs | |||
Overall dimension(L*W*H) mm | 46800×5150×4720 | |||
Front veneer conveyor mm | 11000 | |||
Back veneer conveyor mm | 11000 | |||
Total weight kg | 99,000 | |||
Containers | 40HQ*5 | |||
outline drawing | ||||
 | ||||
| Customer case in CHINA GUANGXI | ||||
| ||||
| Customer case in CHINA YUNNAN | ||||
  | ||||
| | |
| High accuracy control cabinet | High accuracy body and structure |
 |  |
| better veneer mositure | better veneer flatness |
 |  |
| High precision machine ,high precision veneer ,help you make more money ! | |
Contact ： serenda kong Tel/whatsapp : 0086 15588058177 wechat :
| |
