| Quantity: | |
|---|---|
1. Fast work 300pcs per hour 2. Better veneer composer performance 3. Smart control + easy operate . | |||||
No | Parts | Function | (kW) | qty(pc) | Brand |
1 | Veneer Joint | Veneer Pre cut | 3 | 1 | Ri-ding |
Veneer After cut | 3 | 1 | Ri-ding | ||
Pre conveyor | 3 | 1 | Ri-ding | ||
After conveor | 3 | 1 | Ri-ding | ||
Synchronize | 1.5 | 1 | Ri-ding | ||
Fan | 0.18 | 2 | |||
A/C | 1.1 | 1 | Gree | ||
Heating | 8 | ||||
2 | Middle conveyor | 1.5 | 1 | Ri-ding | |
3 | Finger joint | Pull veneer | 1.5 | 1 | Ri-ding |
Pre conveyor | 1.5 | 1 | Ri-ding | ||
Teeth cut | 7.5 | 1 | |||
Middle conveyor | 3 | 1 | Ri-ding | ||
After conveyor | 3 | 1 | Ri-ding | ||
Cut | 3 | 1 | Ri-ding | ||
4 | Stack | Pull veneer | 2.3 | 1 | Ri-ding |
lifting | 3 | 1 | |||
After conveyor | 1.5 | 1 | |||
Out conveyor | 0.75 | 1 | |||
5 | Control box | PLC | DELTA | ||
Electric | Schneider | ||||
Optoelectronic switch | Omron | ||||
6 | Air cylinder system | Solenoid valve | Zhengtai | ||
Air cyliner | ASK | ||||
7 | Overall size | 10m×7.5m×2.5m | |||
8 | Total power | 51.33kW | |||
