Double wide belt sanding machine | |
1, Suit for solid wood board sanding work 2,Whole machine used weld frame structure ,stable and high precision 3, Big diameter roller ,high precision with high frequency work 4,Multi safety guarantee . | |
Model | PR1313-R-P |
1.Sanding board width | 40-1300mm |
2.Sanding board thickness | 2.5-110mm |
3,Sanding board length | ＞780mm |
4.Abrasive belt speed | 25m/s |
5.Size of sanding belt | 1330*2620mm |
6.Main power | 30KW +22KW +18.5KW |
7.Transport reducer | 7.5 kw |
8.feeding speed | 20-40m/s |
9.Lifting motor | 0.75kw |
10.brushing motor | 0.75KW |
11.Total motor | 79.5KW |
12.Operating pressure | 0.6~0.8MPa |
13.Dust extraction | 7900m³/h |
14.Speed of suction extraction | 25`30m/s |
15 Capacity | 200 pc/hour |
16.Dimension | 3140 *2770*2440mm |
17 .Weight | 9800kg |
Double wide belt sanding machine | |
1, Suit for solid wood board sanding work 2,Whole machine used weld frame structure ,stable and high precision 3, Big diameter roller ,high precision with high frequency work 4,Multi safety guarantee . | |
Model | PR1313-R-P |
1.Sanding board width | 40-1300mm |
2.Sanding board thickness | 2.5-110mm |
3,Sanding board length | ＞780mm |
4.Abrasive belt speed | 25m/s |
5.Size of sanding belt | 1330*2620mm |
6.Main power | 30KW +22KW +18.5KW |
7.Transport reducer | 7.5 kw |
8.feeding speed | 20-40m/s |
9.Lifting motor | 0.75kw |
10.brushing motor | 0.75KW |
11.Total motor | 79.5KW |
12.Operating pressure | 0.6~0.8MPa |
13.Dust extraction | 7900m³/h |
14.Speed of suction extraction | 25`30m/s |
15 Capacity | 200 pc/hour |
16.Dimension | 3140 *2770*2440mm |
17 .Weight | 9800kg |
