| Quantity: | |
|---|---|
1, Fast work 2, Stable structure 3, Superior cylinder ,promise stable and strong work | |
Nominal pressure | 800 tons |
Direction of boards in | transverse |
Layers | 10 |
Opening | 100 |
Quantity of hot platens | 11 |
Size of hot platens | 1370×2700×52 Double in double outlet |
Quantity of cylinders | 6 |
Diameter of cylinders | Φ260*6pce |
Stroke of cylinders | 1050 |
Allowed pressure | ≤25 |
Closing time | 10 |
Quick lift cylinder | Φ120mm*2 |
Flow of low pressure pump | 100 |
Allowed pressure | ≤3 |
Power of low pressure pump | 22kw |
Flow of high pressure pump | 25 |
Allowed pressure | ≤25 |
Power of high pressure pump | 11 kw |
Size of finished boards | 1220×2440mm |
Dimension of whole machines | 3600*1370*4300mm |
Controlling methods | Automatic pump station |
Electrical appliances | Schneider |
PLC Brand | TELTA |
Main steel plate | 30mm*4 |
Methods of frames | Assemble |
Weight of whole machine | 34T |
