Automatic loading & unloading for sanding line contains : Auto loading __conveyor ___sanding machine 1#_conveyor __rotate machine ___conveyor___sanding machine 2# Auto unloading
| |
1, Suit for solid wood board sanding work 2, Whole machine used weld frame structure ,stable and high precision 3, Big diameter roller ,high precision with high frequency work 4, Multi safety guarantee . | |
Model | PRS1213R-R |
1.Sanding board width | 40-1300mm |
2.Sanding board thickness | 1-80mm |
3,Sanding board length | ＞780mm |
4.Abrasive belt speed | 25m/s |
5.Size of sanding belt | 1330*2620mm |
6.Main power | 55kw + 45kw |
7.Transport reducer | 7.5kw |
8.feeding speed | 20-40m/s |
9.Lifting motor | 0.75kw |
10.brushing motor | 0.75kw |
11.Total motor | 109kw |
12.Operating pressure | 0.6MPa |
13.Dust extraction | 15000m³/h |
14.Speed of suction extraction | 25=30m/s |
15 Capacity | 200 pc/hour |
16.Dimension | 3030 *2900*2440mm |
17 .Weight | 8200kg |
